At Catford Engineering we offer a wide range of hydraulic products. Browse our one-piece crimp hose fittings pricing below.
If you require a quotation or have any questions, get in touch with our friendly hydraulic experts today.
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C1R1R2-0404 | 1/4″ hose x 1/4″ BSPT Male Straight | $12.50 |
| C1R1R2-0406 | 1/4″ hose x 3/8″ BSPT Male Straight | $13.50 |
| C1R1R2-0606 | 3/8″ hose x 3/8″ BSPT Male Straight | $14.50 |
| C1R1R2-0608 | 3/8″ hose x 1/2″ BSPT Male Straight | $15.50 |
| C1R1R2-0808 | 1/2″ hose x 1/2″ BSPT Male Straight | $16.00 |
| C1R1R2-1212 | 3/4″ hose x 3/4″ BSPT Male Straight | $24.50 |
| C1R1R2-1616 | 1″ hose x 1″ BSPT Male Straight | $40.00 |
BSPT Male
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C2R1R2-0404 | 1/4″ hose x 1/4″ BSP Female Straight | $13.50 |
| C2R1R2-0406 | 1/4″ hose x 3/8″ BSP Female Straight | $15.00 |
| C2R1R2-0606 | 3/8″ hose x 3/8″ BSP Female Straight | $15.50 |
| C2R1R2-0608 | 3/8″ hose x 1/2″ BSP Female Straight | $16.00 |
| C2R1R2-0808 | 1/2″ hose x 1/2″ BSP Female Straight | $18.50 |
| C2R1R2-1212 | 3/4″ hose x 3/4″ BSP Female Straight | $28.00 |
| C2R1R2-1616 | 1″ hose x 1″ BSP Female Straight | $42.50 |
BSP Female
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C27R1R2-0406 | 1/4″ hose x 3/8″ BSP 45° Tube Bend | $23.00 |
| C27R1R2-0606 | 3/8″ hose x 3/8″ BSP 45° Tube Bend | $21.00 |
| C27R1R2-0608 | 3/8″ hose x 1/2″ BSP 45° Tube Bend | $31.00 |
| C27R1R2-0808 | 1/2″ hose x 1/2″ BSP 45° Tube Bend | $26.00 |
| C27R1R2-1010 | 5/8″ hose x 5/8″ BSP 45° Tube Bend | $28.00 |
| C27R1R2-1212 | 3/4″ hose x 3/4″ BSP 45° Tube Bend | $46.00 |
| C27R1R2-1616 | 1″ hose x 1″ BSP 45° Tube Bend | $89.00 |
BSP 45° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C26R1R2-0404 | 1/4″ hose x 1/4″ BSP 90° Tube Bend | $26.50 |
| C26R1R2-0406 | 1/4″ hose x 3/8″ BSP 90° Tube Bend | $28.50 |
| C26R1R2-0606 | 3/8″ hose x 3/8″ BSP 90° Tube Bend | $31.00 |
| C26R1R2-0808 | 1/2″ hose x 1/2″ BSP 90° Tube Bend | $40.00 |
| C26R1R2-1212 | 3/4″ hose x 3/4″ BSP 90° Tube Bend | $48.50 |
| C26R1R2-1616 | 1″ hose x 1″ BSP 90° Tube Bend | $73.00 |
BSP 90° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C3R1R2-0407 | 1/4" hose x 7/16" JIC Male Straight | $13 |
| C3R1R2-0408 | 1/4" hose x 1/2" JIC Male Straight | $13.50 |
| C3R1R2-0409 | 1/4" hose x 9/16" JIC Male Straight | $14.50 |
| C3R1R2-0609 | 3/8" hose x 9/16" JIC Male Straight | $16.00 |
| C3R1R2-0612 | 3/8" hose x 3/4" JIC Male Straight | $17.00 |
| C3R1R2-0614 | 3/8" hose x 7/8" JIC Male Straight | $18.00 |
| C3R1R2-0812 | 1/2" hose x 3/4" JIC Male Straight | $20.00 |
| C3R1R2-0814 | 1/2" hose x 7/8" JIC Male Straight | $20.50 |
| C3R1R2-0817 | 1/2" hose x 1-1/16" JIC Male Straight | $24.50 |
| C3R1R2-1014 | 5/8" hose x 7/8" JIC Male Straight | $25.50 |
| C3R1R2-1017 | 5/8" hose x 1-1/16" JIC Male Straight | $27.00 |
| C3R1R2-1214 | 3/4" hose x 7/8" JIC Male Straight | $29.00 |
| C3R1R2-1217 | 3/4" hose x 1-1/16" JIC Male Straight | $30.50 |
| C3R1R2-1219 | 3/4" hose x 1-3/16" JIC Male Straight | $39.00 |
| C3R1R2-1221 | 3/4" hose x 1-5/16" JIC Male Straight | $44.00 |
| C3R1R2-1621 | 1" hose x 1-5/16" JIC Male Straight | $49.50 |
JIC Male
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C4R1R2-0407 | 1/4″ hose x 7/16″ JIC Female Straight | $12.50 |
| C4R1R2-0408 | 1/4″ hose x 1/2″ JIC Female Straight | $14.00 |
| C4R1R2-0409 | 1/4″ hose x 9/16″ JIC Female Straight | $15.00 |
| C4R1R2-0609 | 3/8″ hose x 9/16″ JIC Female Straight | $15.50 |
| C4R1R2-0612 | 3/8″ hose x 3/4″ JIC Female Straight | $15.50 |
| C4R1R2-0614 | 3/8″ hose x 7/8″ JIC Female Straight | $20.50 |
| C4R1R2-0812 | 1/2″ hose x 3/4″ JIC Female Straight | $22.00 |
| C4R1R2-0814 | 1/2″ hose x 7/8″ JIC Female Straight | $23.00 |
| C4R1R2-0817 | 1/2″hose x 1-1/16″ JIC Female Straight | $25.50 |
| C4R1R2-1014 | 5/8″ hose x 7/8″ JIC Female Straight | $28.00 |
| C4R1R2-1017 | 5/8″ hose x 1-1/16″JIC Female Straight | $28.00 |
| C4R1R2-1214 | 3/4″ hose x 7/8″ JIC Female Straight | $33.00 |
| C4R1R2-1217 | 3/4″ hose x 1-1/16″JIC Female Straight | $33.00 |
| C4R1R2-1219 | 3/4″ hose x 1-3/16″JIC Female Straight | $33.00 |
| C4R1R2-1221 | 3/4″ hose x 1-5/16″JIC Female Straight | $38.50 |
| C4R1R2-1621 | 1″ hose x 1-5/16″ JIC Female Straight | $44.00 |
JIC Female
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C25R1R2-0407 | 1/4″ hose x 7/16″ JIC 45° Tube Bend | $17.50 |
| C25R1R2-0408 | 1/4″ hose x 1/2″ JIC 45° Tube Bend | $20.00 |
| C25R1R2-0409 | 1/4″ hose x 9/16″ JIC 45° Tube Bend | $22.00 |
| C25R1R2-0609 | 3/8″ hose x 9/16″ JIC 45° Tube Bend | $23.00 |
| C25R1R2-0612 | 3/8″ hose x 3/4″ JIC 45° Tube Bend | $29.00 |
| C25R1R2-0812 | 1/2″ hose x 3/4″ JIC 45° Tube Bend | $30.00 |
| C25R1R2-0814 | 1/2″ hose x 7/8″ JIC 45° Tube Bend | $33.00 |
| C25R1R2-0817 | 1/2″ hose x 1-1/16″ JIC 45° Tube Bend | $44.00 |
| C25R1R2-1014 | 5/8″ hose x 7/8″ JIC 45° Tube Bend | $36.00 |
| C25R1R2-1017 | 5/8″ hose x 1-1/16″ JIC 45° Tube Bend | $44.00 |
| C25R1R2-1214 | 3/4″ hose x 7/8″ JIC 45° Tube Bend | $50.00 |
| C25R1R2-1217 | 3/4″ hose x 1-1/16″ JIC 45° Tube Bend | $44.00 |
| C25R1R2-1219 | 3/4″hose x 1-3/16″ JIC 45° Tube Bend | $90.00 |
| C25R1R2-1221 | 3/4″hose x 1-5/16″ JIC 45° Tube Bend | $66.00 |
| C25R1R2-1621 | 1″ hose x 1-5/16″ JIC 45° Tube Bend | $69.00 |
JIC 45° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C7R1R2-0407 | 1/4″ hose x 7/16″ JIC 90° Elbow | $24.00 |
| C7R1R2-0408 | 1/4″ hose x 1/2″ JIC 90° Elbow | $28.00 |
| C7R1R2-0409 | 1/4″ hose x 9/16″ JIC 90° Elbow | $24.00 |
| C7R1R2-0609 | 3/8″ hose x 9/16″ JIC 90° Elbow | $26.00 |
| C7R1R2-0612 | 3/8″ hose x 3/4″ JIC 90° Elbow | $26.50 |
| C7R1R2-0812 | 1/2″ hose x 3/4″ JIC 90° Elbow | $42.00 |
| C7R1R2-0814 | 1/2″ hose x 7/8″ JIC 90° Elbow | $45.00 |
| C7R1R2-0817 | 1/2″ hose x 1-1/16″ JIC 90° Elbow | $46.00 |
| C7R1R2-1217 | 3/4″ hose x 1-1/16″ JIC 90° Elbow | $66.00 |
JIC 90° Elbow
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C24R1R2-0407 | 1/4" hose x 7/16" JIC 90° Tube Bend | $24.50 |
| C24R1R2-0408 | 1/4" hose x 1/2" JIC 90° Tube Bend | $25.50 |
| C24R1R2-0409 | 1/4" hose x 9/16" JIC 90° Tube Bend | $27.50 |
| C24R1R2-0609 | 3/8" hose x 9/16" JIC 90° Tube Bend | $29.00 |
| C24R1R2-0612 | 3/8" hose x 3/4" JIC 90° Tube Bend | $33.00 |
| C24R1R2-0614 | 3/8" hose x 7/8" JIC 90° Tube Bend | $44.00 |
| C24R1R2-0812 | 1/2" hose x 3/4" JIC 90° Tube Bend | $36.50 |
| C24R1R2-0814 | 1/2" hose x 7/8" JIC 90° Tube Bend | $37.00 |
| C24R1R2-0817 | 1/2" hose x 1-1/16" JIC 90° Tube Bend | $47.50 |
| C24R1R2-1014 | 5/8" hose x 7/8" JIC 90° Tube Bend | $45.00 |
| C24R1R2-1017 | 5/8" hose x 1-1/16" JIC 90° Tube Bend | $51.00 |
| C24R1R2-1214 | 3/4" hose x 7/8" JIC 90° Tube Bend | $55.00 |
| C24R1R2-1217 | 3/4" hose x 1-1/16" JIC 90° Tube Bend | $55.00 |
| C24R1R2-1219 | 3/4" hose x 1-3/16" JIC 90° Tube Bend | $65.50 |
| C24R1R2-1221 | 3/4" hose x 1-5/16" JIC 90° Tube Bend | $72.50 |
| C24R1R2-1621 | 1" hose x 1-5/16" JIC 90° Tube Bend | $74.00 |
JIC 90° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C84R1R2-0409 | 1/4″ hose x 9/16″ ORFS Male Straight | $18.00 |
| C84R1R2-0411 | 1/4″ hose x 11/16″ ORFS Male Straight | $20.50 |
| C84R1R2-0611 | 3/8″ hose x 11/16″ ORFS Male Straight | $22.50 |
| C84R1R2-0613 | 3/8″ hose x 13/16″ ORFS Male Straight | $24.50 |
| C84R1R2-0813 | 1/2″ hose x 13/16″ ORFS Male Straight | $30.00 |
| C84R1R2-0816 | 1/2″ hose x 1″ ORFS Male Straight | $34.00 |
| C84R1R2-1016 | 5/8″ hose x 1″ ORFS Male Straight | $36.50 |
| C84R1R2-1019 | 5/8″hose x 1-3/16″ORFS Male Straight | $37.50 |
| C84R1R2-1219 | 3/4″hose x 1-3/16″ORFS Male Straight | $44.00 |
| C84R1R2-1223 | 3/4″hose x 1-7/16″ORFS Male Straight | $60.00 |
| C84R1R2-1623 | 1″ hose x 1-7/16″ ORFS Male Straight | $66.00 |
ORFS Male
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C80R1R2-0409 | 1/4" hose x 9/16" ORFS Female | $18.00 |
| C80R1R2-0411 | 1/4" hose x 11/16" ORFS Female | $22.00 |
| C80R1R2-0611 | 3/8" hose x 11/16" ORFS Female | $24.00 |
| C80R1R2-0613 | 3/8" hose x 13/16" ORFS Female | $26.50 |
| C80R1R2-0813 | 1/2" hose x 13/16" ORFS Female | $30.00 |
| C80R1R2-0816 | 1/2" hose x 1" ORFS Female | $31.00 |
| C80R1R2-1016 | 5/8" hose x 1" ORFS Female | $36.50 |
| C80R1R2-1019 | 5/8" hose x 1-3/16" ORFS Female | $44.00 |
| C80R1R2-1216 | 3/4" hose x 1" ORFS Female | $45.50 |
| C80R1R2-1219 | 3/4" hose x 1-3/16" ORFS Female | $50.50 |
| C80R1R2-1223 | 3/4" hose x 1-7/16" ORFS Female | $55.00 |
| C80R1R2-1623 | 1" hose x 1-7/16" ORFS Female | $60.00 |
ORFS Female
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C81R1R2-0409 | 1/4″ hose x 9/16″ ORFS 45°Tube Bend | $22.00 |
| C81R1R2-0411 | 1/4″ hose x 11/16″ ORFS 45°Tube Bend | $24.00 |
| C81R1R2-0611 | 3/8″ hose x 11/16″ ORFS 45°Tube Bend | $25.00 |
| C81R1R2-0613 | 3/8″ hose x 13/16″ ORFS 45°Tube Bend | $26.50 |
| C81R1R2-0813 | 1/2″ hose x 13/16″ ORFS 45°Tube Bend | $28.00 |
| C81R1R2-0816 | 1/2″ hose x 1″ ORFS 45°Tube Bend | $44.00 |
| C81R1R2-1016 | 5/8″ hose x 1″ ORFS 45°Tube Bend | $50.00 |
| C81R1R2-1019 | 5/8″hose x 1-3/16″ORFS 45°Tube Bend | $61.00 |
| C81R1R2-1219 | 3/4″hose x 1-3/16″ORFS 45°Tube Bend | $57.50 |
| C81R1R2-1223 | 3/4″hose x 1-7/16″ORFS 45°Tube Bend | $86.00 |
| C81R1R2-1623 | 1″ hose x 1-7/16″ORFS 45°Tube Bend | $93.00 |
ORFS 45° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C82R1R2-0409 | 1/4″ hose x 9/16″ ORFS 90°Tube Bend | $23.50 |
| C82R1R2-0411 | 1/4″ hose x 11/16″ ORFS 90°Tube Bend | $25.00 |
| C82R1R2-0609 | 3/8″ hose x 9/16″ ORFS 90°Tube Bend | $26.50 |
| C82R1R2-0611 | 3/8″ hose x 11/16″ ORFS 90°Tube Bend | $27.50 |
| C82R1R2-0613 | 3/8″ hose x 13/16″ ORFS 90°Tube Bend | $33.00 |
| C82R1R2-0813 | 1/2″ hose x 13/16″ ORFS 90°Tube Bend | $35.00 |
| C82R1R2-0816 | 1/2″ hose x 1″ ORFS 90°Tube Bend | $40.00 |
| C82R1R2-1019 | 5/8″hose x 1-3/16″ORFS 90°Tube Bend | $58.50 |
| C82R1R2-1219 | 3/4″hose x 1-3/16″ORFS 90°Tube Bend | $58.50 |
| C82R1R2-1223 | 3/4″hose x 1-7/16″ORFS 90°Tube Bend | $88.00 |
| C82R1R2-1623 | 1″ hose x 1-7/16″ORFS 90°Tube Bend | $95.00 |
ORFS 90° Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C65R1R2-0412 | 1/4″ hose x 12mm DKL Metric Male | $16.50 |
| C65R1R2-0414 | 1/4″ hose x 14mm DKL Metric Male | $17.00 |
| C65R1R2-0616 | 3/8″ hose x 16mm DKL Metric Male | $20.50 |
| C65R1R2-0618 | 3/8″ hose x 18mm DKL Metric Male | $22.00 |
| C65R1R2-0822 | 1/2″ hose x 22mm DKL Metric Male | $27.00 |
| C65R1R2-0826 | 1/2″ hose x 26mm DKL Metric Male | $28.00 |
| C65R1R2-1026 | 5/8″ hose x 26mm DKL Metric Male | $33.00 |
| C65R1R2-1230 | 3/4″hose x 30mm DKL Metric Male | $34.00 |
| C65R1R2-1236 | 3/4″hose x 36mm DKL Metric Male | $66.00 |
| C65R1R2-1636 | 1″ hose x 36mm DKL Metric Male | $77.00 |
DKL Metric Male
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C60R1R2-0412 | 1/4″hose x 12mm DKOL Metric Female | $18.50 |
| C60R1R2-0414 | 1/4″hose x 14mm DKOL Metric Female | $19.50 |
| C60R1R2-0616 | 3/8″hose x 16mm DKOL Metric Female | $22.00 |
| C60R1R2-0618 | 3/8″hose x 18mm DKOL Metric Female | $22.50 |
| C60R1R2-0822 | 1/2″hose x 22mm DKOL Metric Female | $27.00 |
| C60SR1R2-0824 | 1/2″hose x 24mm DKOS Metric Female | $30.00 |
| C60R1R2-0826 | 1/2″hose x 26mm DKOL Metric Female | $33.00 |
| C60R1R2-1026 | 5/8″hose x 26mm DKOL Metric Female | $34.50 |
| C60R1R2-1230 | 3/4″hose x 30mm DKOL Metric Female | $41.50 |
| C60R1R2-1236 | 3/4″hose x 36mm DKOL Metric Female | $55.00 |
| C60R1R2-1636 | 1″ hose x 36mm DKOL Metric Female | $77.00 |
DKOL Metric Female
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C66R1R2-0412 | 1/4″hose x 12mm 45°Metric TubeBend | $22.00 |
| C66R1R2-0414 | 1/4″hose x 14mm 45°Metric TubeBend | $22.50 |
| C66R1R2-0616 | 3/8″hose x 16mm 45°Metric TubeBend | $24.00 |
| C66R1R2-0618 | 3/8″hose x 18mm 45°Metric TubeBend | $24.50 |
| C66R1R2-0822 | 1/2″hose x 22mm 45°Metric TubeBend | $33.00 |
| C66SR1R2-0824 | 1/2″hose x 24mm 45°Metric TubeBend | $39.50 |
| C66R1R2-0826 | 1/2″hose x 26mm 45°Metric TubeBend | $42.00 |
| C66R1R2-1026 | 5/8″hose x 26mm 45°Metric TubeBend | $48.00 |
| C66R1R2-1230 | 3/4″hose x 30mm 45°Metric TubeBend | $75.50 |
| C66R1R2-1636 | 1″ hose x 36mm 45°Metric TubeBend | $107.00 |
DKOL Metric 45°Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C67R1R2-0412 | 1/4″hose x 12mm 90°Metric TubeBend | $22.00 |
| C67R1R2-0414 | 1/4″hose x 14mm 90°Metric TubeBend | $22.50 |
| C67R1R2-0616 | 3/8″hose x 16mm 90°Metric TubeBend | $24.00 |
| C67R1R2-0618 | 3/8″hose x 18mm 90°Metric TubeBend | $24.50 |
| C67R1R2-0822 | 1/2″hose x 22mm 90°Metric TubeBend | $33.00 |
| C67SR1R2-0824 | 1/2″hose x 24mm 90°Metric TubeBend | $48.00 |
| C67R1R2-0826 | 1/2″hose x 26mm 90°Metric TubeBend | $49.00 |
| C67R1R2-1026 | 5/8″hose x 26mm 90°Metric TubeBend | $55.00 |
| C67R1R2-1230 | 3/4″hose x 30mm 90°Metric TubeBend | $78.00 |
| C67R1R2-1636 | 1″ hose x 36mm 90°Metric TubeBend | $110.00 |
DKOL Metric 90°Tube Bend
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C23R1R2-0404 | 1/4″hose x 1/4″ Diam Weld-On | $14.50 |
| C23R1R2-0405 | 1/4″hose x 5/16″ Diam Weld-On | $15.50 |
| C23R1R2-0406 | 1/4″hose x 3/8″ Diam Weld-On | $16.50 |
| C23R1R2-0606 | 3/8″hose x 3/8″ Diam Weld-On | $16.50 |
| C23R1R2-0608 | 3/8″hose x 1/2″ Diam Weld-On | $17.50 |
| C23R1R2-0808 | 1/2″hose x 1/2″ Diam Weld-On | $20.00 |
| C23R1R2-0810 | 1/2″hose x 5/8″ Diam Weld-On | $34.00 |
| C23R1R2-1010 | 5/8″hose x 5/8″ Diam Weld-On | $35.00 |
| C23R1R2-1012 | 5/8″hose x 3/4″ Diam Weld-On | $36.00 |
| C23R1R2-1212 | 3/4″hose x 3/4″ Diam Weld-On | $36.00 |
| C23R1R2-1616 | 1″ hose x 1″ Diam Weld-On | $53.50 |
Weld-On Lifesaver
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C90R1R2-0404 | 1/4″hose x 1/4″ Salvage Hose Joiner | $42.00 |
| C90R1R2-0606 | 3/8″hose x 3/8″ Salvage Hose Joiner | $22.00 |
| C90R1R2-0808 | 1/2″hose x 1/2″ Salvage Hose Joiner | $25.00 |
| C90R1R2-1010 | 5/8″hose x 5/8″ Salvage Hose Joiner | $66.00 |
| C90R1R2-1212 | 3/4″hose x 3/4″ Salvage Hose Joiner | $77.00 |
| C90R1R2-1616 | 1″hose x 1″ Salvage Hose Joiner | $129.00 |
Hose Joiner
| Part Numbers | Description | Price Inc. GST |
|---|---|---|
| C4R4-1217 | 3/4″ hose x 1 1/16″ JIC Female | $24.50 |
| C4R4-1219 | 3/4″ hose x 1 3/16″ JIC Female | $40.00 |
| C4R4-1621 | 1″ hose x 1 5/16″ JIC Female | $42.00 |
| C4R4-2026 | 1 1/4″ hose x 1 5/8″ JIC Female | $76.00 |
Four Wire JIC Female
|
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| C | 1 | R1 R2 R4 | 04 | 04 | |||||
| (1) C – The fitting is one piece crimp | (4) 04 – 1/4″ | (5) 04 – 1/4″ | |||||||
| (2) 1 – BSPT male thread | 06 – 3/8″ | 06 – 3/8″ | |||||||
| 2 – BSP female thread | 08 – 1/2″ | 07 – 7/16″ | |||||||
| 3 – JIC male thread | 10 – 5/8″ | 08 – 1/2″ | |||||||
| 4 – JIC female thread | 12 – 3/4″ | 09 – 9/16″ | |||||||
| 24 – JIC female 90° tube bend | 16 – 1″ | 11 – 11/16″ | |||||||
| 25 – BSP female 90° tube bend | 20 – 1-1/4″ | 12 – 3/4″ | |||||||
| 80 – ORFS female flat face | 13 – 13/16″ | ||||||||
| (3) R1 R2 Is one & two wire braid non-skive hose | 14 – 7/8″ | ||||||||
| R4 4 wire braid non-skive hose | 16 – 1″ | ||||||||
| 17 – 1-1/16″ | |||||||||
| 19 – 1-3/16″ | |||||||||
| 21 – 1-5/16″ | |||||||||
| 23 – 1-7/16″ | |||||||||
| Single Braid Non-Skive SAE100R1AT HOSES | Double Braid non-Skive SAE100R2AT HOSES | 4SP-EN856 FOUR WIRE HOSES | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hose | Dash Size | Hose Length A | Before Crimping B | After Crimping c | Hose | Dash Size | Hose Length A | Before Crimping B | After Crimping C | Hose | Dash Size | Hose Length A | Before Crimping B | After Crimping c |
| 1/4″ | 04 | 19.5mm | 22.5mm | 17mm-17.2mm | 1/4″ | 04 | 19.5mm | 22.5mm | 18mm-18.3mm | 3/8″ | 06 | |||
| 3/8″ | 06 | 22mm | 27mm | 20.1mm-20.3mm | 3/8″ | 06 | 22mm | 27mm | 21.3mm-21.5mm | 1/2″ | 08 | |||
| 1/2″ | 08 | 27mm | 31.5mm | 24mm-24.6mm | 1/2″ | 08 | 27mm | 31.5mm | 25mm-25.3mm | 3/4″ | 12 | 35mm | 42mm | 35.8-36mm |
| 5/8″ | 10 | 35mm | 35mm | 28.2mm-28.4mm | 5/8″ | 10 | 35mm | 35mm | 28.6mm-28.8mm | 1″ | 16 | 45mm | 51.2mm | 43mm |
| 3/4″ | 12 | 37mm | 39.7mm | 33.5mm-33.7mm | 3/4″ | 12 | 37mm | 39.7mm | 32.5mm-33mm | 11/4″ | 20 | 46mm | 60.6mm | 50.6-51mm |
| 1″ | 16 | 43mm | 48.5mm | 39.4mm-39.7mm | 1″ | 16 | 43mm | 48.5mm | 40.4mm-40.7mm | |||||
Lot 25, Mannanarie Road, JAMESTOWN SA
PO Box 178 , JAMESTOWN South Australia 5491
